Description
Bitumen 80/100 and 85/100
Bitumen 80/100 would be in the category of standard types of penetration bitumen and this Grade of Bitumen is widely used in road construction.
Bitumen 80/100 has Thermoplastic properties, this property has a direct effect on the viscosity of bitumen, which increases the viscosity at low temperatures and decreases the viscosity at high temperatures.
It is worth mentioning that one of the other important applications of Bitumen 80/100 would be in the preparation of hot asphalt and road surface.
Bitumen 80/100 Applications:
The use of bitumen depends on the climatic conditions of those areas, for example, in areas with hot Climates, hard bitumen with a lower degree of penetration will use, and also in areas with colder Climates, softer bitumen with a higher degree of penetration will use.
According to this explanation, the Bitumen 80/100 or 85/100 has normally used in Roads Asphalt, Coating, Waterproof roofing felt, and,…
Bitumen 80/100 Packing:
Jumbo Bag Method:
In this type of packaging method, it is a two-layer bag with a sack outer layer and a nylon inner layer. This type of packaging is used to transport bitumen 80/100 for export.
Drum Packing Method:
This bitumen packing method is also used to transport bitumen 80/100 for export and the carrying capacity of any type of freight would be as follows:
1. Number of Drums per floor – 90 Drums with pallets and about 115 Drums without pallets.
2. Number of Drums in each 20-foot container: 80 Drums with pallets and 110 Drums without pallets.
3. Number of Drums in each 40-foot container: 137 Drums with pallets and 150 Drums without pallets.
Packing By Polybag Method:
Another widely used packing method to carry bitumen 80/100 would be the polybag method, this product has a bag whose outer layer is made of sack and polypropylene and the inner layer is made of nano nylon. It has a high resistance to heat, it is very light and easy to carry.
Asia Bitumen factory would be one of the major suppliers and exporters of bitumen 80/100 in the middle east, Which has gained its rank and position in this field and has the ability to sell its Bitumen as soon as possible with the best quality, competitive prices, and with proper packaging according to the type of bitumen.
Bitumen 80/100 Specification:
SPECIFICATION | TEST METHOD | A.S.T.M. |
SPECIFIC GRAVITY AT 25/25 DEG C | 1.01/1.05 | D.70 |
PENETRATION AT 25 DEG C | 85/100 | D.5 |
SOFTENING POINT DEG C | 45/52 | D.36 |
DUCTILITY AT 25 DEG C CMS | 100 MIN | D.113 |
LOSS ON HEATING PCT WT | 0.5 MAX | D.6 |
DROP IN PENETRATION AFTER HEATING PCT | 20 MAX | D.5 |
FLASH POINT DEG C | 225 MIN | D.92 |
SOLUBILITY IN CS2 PCT WT | 99.5 MIN | D.4 |
ORGANIC MATTER INSOLUBLE IN CS2 PCT WT | 0.2 MAX | D.4 |
SPOT TEST | NEGATIVE | *A.A.S.H.O T102-42 |
Bitumen 85/100 Specification:
SPECIFICATION | TEST METHOD | A.S.T.M. |
SPECIFIC GRAVITY AT 25/25 DEG C | 1.01/1.05 | D.70 |
PENETRATION AT 25 DEG C | 85/100 | D.5 |
SOFTENING POINT DEG C | 45/52 | D.36 |
DUCTILITY AT 25 DEG C CMS | 100 MIN | D.113 |
LOSS ON HEATING PCT WT | 0.5 MAX | D.6 |
DROP IN PENETRATION AFTER HEATING PCT | 20 MAX | D.5 |
FLASH POINT DEG C | 225 MIN | D.92 |
SOLUBILITY IN CS2 PCT WT | 99.5 MIN | D.4 |
ORGANIC MATTER INSOLUBLE IN CS2 PCT WT | 0.2 MAX | D.4 |
SPOT TEST | NEGATIVE | *A.A.S.H.O T102-42 |
